Helix M Six

Output power RMS / max.
- @ 4 Ohms 6 x 100 / 200 Watts
- @ 2 Ohms 6 x 100 / 200 Watts
- @ 1 Ohm -
- bridged @ 4 Ohms 3 x 200 / 400 Watts
- bridged @ 2 Ohms -
Amplifier technology Class D
Inputs 6 x RCA / Cinch
1 x Remote In
Input sensitivity RCA / Cinch 0.5 - 6 Volts
Input impedance RCA / Cinch 20 kOhms
Input impedance highlevel -
Outputs 6 x Speaker output
Output voltage RCA / Cinch -
Signal converter for digital input -
Frequency response 10 Hz - 30,000 Hz
Bass boost -
Highpass 15 Hz - 4,000 Hz adjustable
Lowpass 40 Hz - 4,000 Hz adjustable
Bandpass 15 Hz - 4,000 Hz adjustable
Subsonic / HPF
15 Hz - 4,000 Hz adjustable
Phase -
Slope high- / lowpass 12 dB/Oct.
Slope subsonic / lowpass -
Signal-to-noise ratio digital input -
Signal-to-noise ratio analog input 98 dB (A-weighted)
Distortion (THD) 0.05 %
Damping factor 100
Operating voltage 10.5 - 16 Volts (max. 5 sec. down to 6 Volts)
Idle current 1,550 mA
Fuse 2 x 35 A Maxi-fuse (APX)
Additional features Active, adjustable crossover, subsonic input mode switch channel E / F, subsonic, Start-Stop capability
Dimensions (H x W x D) 50 x 320 x 154 mm /
2.00 x 12.60 x 6.06”
